2.5G/5G BASE-T 以太网变压器
数据速率 |
安装方法 |
端口 |
PIN脚 |
Pitch |
工作温度 |
Vt (V (RMS)) |
PoE |
|---|
| | | | | | | |
|---|
2.5/5G Base-T | SMD | 双口 | 48 | 1.02mm | -40 up to +85 °C | 1500 | PoE+ (up to 720 mA) |
2.5/5G Base-T | SMD | 双口 | 48 | 1.02mm | -40 up to +85 °C | 1500 | 4PPoE (up to 1200 mA) |
2.5/5G Base-T | SMD | 双口 | 48 | 1.02mm | 0 up to 70 °C | 1500 | 4PPoE (up to 1000 mA) |
2.5/5G Base-T | SMD | 双口 | 48 | 1.02mm | 0 up to 70 °C | 1500 | 4PPoE (up to 1000 mA) |
2.5/5G Base-T | SMD | 双口 | 48 | 1.02mm | 0 up to 70 °C | 1500 | 4PPoE (up to 350 mA) |
2.5/5G Base-T | SMD | 双口 | 48 | 1.02mm | 0 up to 70 °C | 1500 | non-PoE |
2.5/5G Base-T | SMD | 单口 | 24 | 1.27mm | -40 up to +85 °C | 1500 | 4PPoE (up to 1000 mA) |
2.5/5G Base-T | SMD | 单口 | 24 | 1.27mm | 0 up to 70 °C | 1500 | 4PPoE (up to 350 mA) |
2.5/5G Base-T | SMD | 单口 | 24 | 1.27mm | -40 up to +85 °C | 1500 | 4PPoE (up to 800 mA) |
2.5/5G Base-T | SMD | 单口 | 24 | 1.27mm | 0 up to 70 °C | 1500 | 4PPoE (up to 350 mA) |
2.5/5G Base-T | SMD | 单口 | 24 | 1.27mm | 0 up to 70 °C | 1500 | non-PoE |
2.5/5G Base-T | SMD(低高度) | 单口 | 24 | 1.27mm | 0 up to 70 °C | 1500 | non-PoE |
2.5/5G Base-T | SMD(低高度) | 单口 | 24 | 1.27mm | 0 up to 70 °C | 1500 | non-PoE |
2.5/5G Base-T | SMD | 单口 | 24 | 1.0mm | 0 up to 70 °C | 1500 | PoE+ (up to 720 mA) |
2.5/5G Base-T | SMD | 单口 | 24 | 1.0mm | 0 up to 70 °C | 1500 | 4PPoE (up to 350 mA) |
2.5/5G Base-T | SMD | 单口 | 24 | 1.0mm | -40 up to +85 °C | 1500 | non-PoE |
2.5/5G Base-T | SMD | 单口 | 24 | 1.0mm | 0 up to 70 °C | 1500 | non-PoE |
2.5/5G Base-T | SMD | 双口 | 48 | 1.02mm | -40 up to +85 °C | 1500 | 4PPoE (up to 1200 mA) |
![]()
